EDID-8K60-P1 | HDMI 8K60 EDID Feeder
Product No.: EDID-8K60-P1
The HDMI 8K60 EDID Feeder eliminates common EDID handshake issues with KVMs, extenders, splitters and HDMI matrix switches. This compact EDID emulator supports 8K@60Hz / 4K@120Hz HDR EDID cloning and HDCP 2.3 pass-through. It comes with 8 independent EDID memory slots, quickly cloning display EDID in less than 10 seconds via simple DIP-switch selection. Great for professional AV installers, system integrators and test benches to maintain stable HDMI signal between legacy and new HDMI devices.
Buyer login — pricing, stock and order history
Incoterms® 2020 Applies to all Tittron B2B orders.
Overview — EDID-8K60-P1 | HDMI 8K60 EDID Feeder
The HDMI 8K60 EDID Feeder adapter stabilizes HDMI handshakes for AV systems plagued by EDID-related failures when deploying KVM switches, HDMI extenders, splitters and matrix switches. Its compact, minimalist form factor delivers a practical connectivity tool for professional AV and IT installers, enabling seamless interoperability between legacy and modern HDMI hardware without sacrificing signal performance. This EDID emulator supports resolutions up to 7680×4320@60Hz and 3840×2160@120Hz HDR via EDID cloning, alongside HDCP 2.3 pass-through, compatible with nearly all HDMI source and display devices.
The adapter directly clones EDID metadata from your target HDMI display, feeding consistent, accurate display information back to your graphics card or video source. By locking in the display EDID configuration, it resolves frequent headaches including wrong resolution output, intermittent screen blackouts and HDMI handshake failures. It is an indispensable tool for commercial AV deployments, lab testing environments and system integration projects.
It features 8 independent EDID memory banks, capable of saving up to eight separate EDID profiles simultaneously. Each memory slot stores a unique EDID preset, letting you toggle between different displays, resolutions and AV setups without re-cloning EDID repeatedly. Built-in DIP switches offer instant profile selection, delivering dependable control and streamlined workflows for multi-screen installations and repeat rollouts. EDID cloning completes in under 10 seconds. Fast capture, storage and deployment make it ideal for tight-deadline jobs and bulk installation projects. See the technical documentation for full specifications and step-by-step operation guides.
What stands out — EDID-8K60-P1 | HDMI 8K60 EDID Feeder
- ■ Continuously emulates HDMI® EDID information
- ■ Supports resolutions up to 7680x4320@60Hz or 3840x2160@120Hz with additional support for HDR
- ■ Used cloned data in up to 8 pre-stored resolutions/timings
- ■ Headless connection (no monitor connection required)
Technical specifications — EDID-8K60-P1 | HDMI 8K60 EDID Feeder
- Model
- EDID-8K60-P1
- AV Interface
- HDMI
- Interface Standard
- 2.1
- Supported Bandwidth
- 48Gbps
- Maximum Resolution
- 7680x4320@60Hz 4:4:4 10Bit
- Audio EDID
- Sample size: 16 to 24 bits, sample rates: 32kHz up to 192kHz
- HDCP Support
- HDCP 2.3
- Special Features
- Headless connection (no monitor connection required)
- Input
- HDMI Male
- Output
- HDMI Female
- Power
- Via HDMI source interface
- Data
- USB-C
- Dimensions WxDxH
- 64.5x22.5x11mm
- Housing Material
- ABS
- Net Weight
- 0.01Kg
- Operating Temperature
- 0°C - 50°C (32°F - 122°F)
- Storage Temperature
- -20°C - 70°C (-4°F - 158°F)
- Humidity
- 0-80% RH (non-condensing)
- Warranty
- 12 months
- Certification
- CE · FCC · RoHS
- OEM / ODM
- Supported
DOWNLOAD — EDID-8K60-P1 | HDMI 8K60 EDID Feeder
Datasheets, drivers and firmware for this model are not published yet. Contact our team and we will send the files you need.
GET A QUOTE
Need a quotation or a private-label programme?
Send us the models, quantities and target market. We reply with pricing, lead time and certification details.
